P1LB22/480
P1LB22/480
- 100,000-Hour LED lifespan
- IP65 rating protects against dust and water
- 10-Year, Limited warranty
Performance
| Watts | 850W |
| Color Temp | 5700K |
| Lumens | 123,911 lm |
| Efficacy | 144.7 |
| Color Accuracy | 74 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | 4.18A |
| 240V | 3.63A |
| 277V | 3.15A |
| Input Watts | 856.1W |
Dimensions
Weight: 56.7 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Electrical
Driver
Constant Current, Class 1, 200-480V, 50/60 Hz, 208V: 4.18A 240V: 3.63A, 277V: 3.15A, 480V: 1.86A
Dimming Driver
Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.
THD
20.51% at 480V
Power Factor
94.9% at 480V
Surge Protection
20 kV
Aux Power Supply
Yes
Dim to Off
Yes
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
3000W Metal Halide
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 122°F (50°C)
Housing
Precision die-cast aluminum
Lens
Polycarbonate lens
Tilt Increment
Continuous tilting with 5° increments
Effective Projected Area (With Shield)
0°: 1.67
15°: 1.7642
25°: 1.8914
45°: 2.2483
60°: 2.4786
75°: 2.6644
90°: 2.774
15°: 1.7642
25°: 1.8914
45°: 2.2483
60°: 2.4786
75°: 2.6644
90°: 2.774
Gaskets
High-temperature silicone
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Trunnion mount with stainless steel hardware
Optical
NEMA Type
NEMA Beam Spread 2H x 2V
Other
10-Year Limited Warranty
The RAB 10-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
