P1SB22

100,000-Hour LED lifespan

IP65 rating protects against dust and water

10-Year, Limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	500W
Color Temp	5700K
Lumens	72,476 lm
Efficacy	143.1
Color Accuracy	74 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	4.31A
208V	2.48A
240V	2.15A
277V	1.86A
Input Watts	506.6W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 36.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.

IP Rating

Ingress protection rating of IP65 for dust and water

DLC Listed

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-PL8YHP

Electrical

Driver

Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 4.31A, 208V: 2.48A, 240V: 2.15A, 277V: 1.86A

Dimming Driver

Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.

THD

9.05% at 120V, 6.58% at 277V

Power Factor

99.6% at 120V, 96.5% at 277V

Surge Protection

10 kV

Aux Power Supply

Yes

Dim to Off

Yes

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

1500W Metal Halide

Construction

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 122°F (50°C)

Housing

Precision die-cast aluminum

Lens

Polycarbonate lens

Tilt Increment

Continuous tilting with 5° increments

Effective Projected Area (With Shield)

0°: 1.2864
15°: 1.2934
25°: 1.43
45°: 1.7071
60°: 1.873
75°: 2.0015
90°: 2.0669

Gaskets

High-temperature silicone

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Trunnion mount with stainless steel hardware

Optical

NEMA Type

NEMA Beam Spread 2H x 2V

Other

10-Year Limited Warranty

The RAB 10-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
