P1MB33/480
P1MB33/480
- 100,000-Hour LED lifespan
- IP65 rating protects against dust and water
- 10-Year, Limited warranty
Performance
| Watts | 600W |
| Color Temp | 5700K |
| Lumens | 84,882 lm |
| Efficacy | 143.8 |
| Color Accuracy | 76 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | 3.01A |
| 240V | 2.61A |
| 277V | 2.26A |
| Input Watts | 590.4W |
Dimensions
Weight: 36.5 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-H3LFFS
DLC Product Code: S-H3LFFS
Electrical
Driver
Constant Current, Class 1, 200-480V, 50/60 Hz, 208V: 3.01A 240V: 2.61A, 277V: 2.26A, 480V: 1.31A
Dimming Driver
Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.
THD
4.51% at 480V
Power Factor
97.2% at 480V
Surge Protection
20kV
Aux Power Supply
Yes
Dim to Off
Yes
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Construction
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Maximum Ambient Temperature
Suitable for use in up to 50°C (122°F)
Housing
Precision die-cast aluminum
Lens
Polycarbonate lens
Tilt Increment
Continuous tilting with 5° increments
Effective Projected Area (With Shield)
0°: 1.2864
15°: 1.2934
25°: 1.43
45°: 1.7071
60°: 1.873
75°: 2.0015
90°: 2.0669
15°: 1.2934
25°: 1.43
45°: 1.7071
60°: 1.873
75°: 2.0015
90°: 2.0669
Gaskets
High-temperature silicone
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Trunnion mount with stainless steel hardware
\
Optical
NEMA Type
NEMA Beam Spread 3H x 3V
Other
10 Yr Limited Warranty
The RAB 10-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
