W34L
150W 3000/4000/5000K
- 100,000-Hour LED lifespan
- 0-10V dimming standard
- 5-Year, limited warranty
Performance
| Watts | 150/100/75W |
| Color Temp | 3000/4000/5000K |
| Lumens | 11,480-21,852 lm |
| Efficacy | 141.8-169.1 lm/W |
| Color Accuracy | 72-75 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 1.25A/0.84A/0.63A |
| 208V | 0.73A/0.48A/0.36A |
| 240V | 0.63A/0.42A/0.32A |
| 277V | 0.55A/0.37A/0.28 |
| Input Watts | 70.4-145W |
Dimensions
Weight: 13.0 lbs
Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
150W/100W/75W (factory default 150W)
Color temperature selectable by 5000K, 4000K and 3000K
150W/100W/75W (factory default 150W)
Color temperature selectable by 5000K, 4000K and 3000K
Compliance
UL Listed
Suitable for wet locations
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-LHG3FY
DLC Product Code: S-LHG3FY
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60Hz:
150W: 120V: 1.25A, 208V: 0.73A, 240V: 0.63A, 277V: 0.55A
100W: 120V: 0.84A, 208V: 0.48A, 240V: 0.42A, 277V: 0.37A
75W: 120V: 0.63A, 208V: 0.36A, 240V: 0.32A, 277V: 0.28A
150W: 120V: 1.25A, 208V: 0.73A, 240V: 0.63A, 277V: 0.55A
100W: 120V: 0.84A, 208V: 0.48A, 240V: 0.42A, 277V: 0.37A
75W: 120V: 0.63A, 208V: 0.36A, 240V: 0.32A, 277V: 0.28A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
3.53% at 120V, 8.91% at 277V
Power Factor
99.7% at 120V, 93.2% at 277V
Photocell
Integrated photocell included with on/off switch
Performance
Lifespan
100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Wattage Equivalency
150W: Replaces up to 750W Metal Halide or 400W High Pressure Sodium
100W: Replaces up to 400W Metal Halide or 310W High Pressure Sodium
75W: Replaces up to 350W Metal Halide or 250W High Pressure Sodium
100W: Replaces up to 400W Metal Halide or 310W High Pressure Sodium
75W: Replaces up to 350W Metal Halide or 250W High Pressure Sodium
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Housing
Die-cast aluminum
Lens
Glass
Reflector
Specular aluminum
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Maximum Ambient Temperature
Suitable for use in up to 40°C (104°F)
Green Technology
Mercury and UV free. RoHS-compliant components.
Finish
Formulated for high durability and long-lasting color
Installation
Mounting
Die-cast backbox with four (4) conduit entry points and knockout pattern for junction box or direct wall mounting. Hinged door for easy re-assembly.
Optical
BUG Rating
150W: B1 U3 G5
100W: B1 U3 G5
75W: B1 U3 G5
100W: B1 U3 G5
75W: B1 U3 G5
Other
5 Yr Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
