HA6
HA6
- 45-degree optical lens provides uniform light distribution
- Dimmable, see Dimmer Compatibility List
- IC and airtight rated
- Separate snap-in color trims available in round, square, smooth and baffle for in-field installation
- 50,000-Hour LED lifespan
- 5-Year, no compromise warranty
Performance
| Watts | 18W |
| Color Temp | 2700/3000/3500/4000/5000K |
| Lumens | 2,000 lm |
| Efficacy | 111.1 |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.17A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 18W |
Dimensions
Weight: 1.2 lbs
Technical Specifications
Performance
Description
6-inch LED downlight module for HALED
Product Type
Recessed Downlights
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Dimming
Yes, See Dimmer Compatibility List
Electrical
Driver
120V, 60 Hz, 0.17A
THD
≤20%
Power Factor
0.9
Input Voltage
120V.
For 120-277V applications, order with HAD6/D10 (sold separately).
For 120-277V applications, order with HAD6/D10 (sold separately).
Operating Frequency
60 Hz
LED Characteristics
Color Temperature
Field Adjustable: 2700K,3000K,3500K,4000K,5000K
Color Stability
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Downlight Module Component
This component must be ordered with the 6" HALED trim in order to make a complete fixture.
See here for Round & Square 6" HALED Trims
See here for Round & Square 6" HALED Trims
Material
Metal
Trim Style
Smooth Trim
Shape
Round
Operating Temperature Range
-4°F - 104°F (-20°C - 40°C)
Expose to UV Light
Yes
Compliance
UL Listed
Suitable for wet locations
Energy Star Approved
This product is ENERGY STAR® Version 2.2 Certified.
FCC
Complies with Part 15B of the FCC Rules
California Title 24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6.
IC Rated
Suitable for direct contact with insulation.
Type IC inherently protected, suitable for direct contact to air permeable insulation and cULus listed for damp locations.
Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013.
Type IC inherently protected, suitable for direct contact to air permeable insulation and cULus listed for damp locations.
Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013.
Air Tight
Airtight per ASTM-E283-04
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
Energy Star ID
3554023
Installation
Mounting
Recessed ceiling
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Compatible Accessories
DRI-EMB-15S-LV
2-n-1 Driver + Battery Backup
2-n-1 Driver + Battery Backup
