WPTLED25W/D10/PC2

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

WPTLED25W/D10/PC2

Covers footprints of most HID tall packs

0-10V dimmable driver & 120 - 277V photocell

Vandal-resistant lens

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	25W
Color Temp	5000K (Cool)
Lumens	2,730 lm
Efficacy	131.3
Color Accuracy	77 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.17A
208V	0.10A
240V	0.09A
277V	0.08A
Input Watts	20.8W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 6.3 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations. Wall mount only.

IP Rating

Ingress protection rating of IP66 for dust and water

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to 70W Metal Halide/50W HPS

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Stability

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Maximum Ambient Temperature

Suitable for use in up to -40°F (-40°C) to 104°F (40°C )

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Thermal Management

Superior thermal management with die-cast aluminum heatsink

Housing

Precision die-cast aluminum

Refractor Lens

High-impact, diffuse, UV-stabilized polycarbonate

Reflector

High-gloss white aluminum

Gaskets

High-temperature silicone gaskets

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Three (3) 1/2" NPS conduit entry points (2 sides for through-feed, and bottom), and drilling template for easy wall box mounting

Electrical

Driver

Constant Current, Class 2, 120-277V, 50-60Hz, 120V: 0.17A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A

Dimming Driver

0-10V dimming driver standard for ultimate flexibility. Use as on/off or utilize the 0-10V DC dimming circuit for controls.

THD

15.43% at 120V, 11.21% at 277V

Power Factor

96.9% at 120V, 94.1% at 277V

Photocell

Photocell is rated for 120V thru 277V. to disable, simply use the provide silicone rubber cap and cover.

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Patents

The design of WPTLED is protected by patents pending in US, Canada, China, Taiwan and Mexico

Optical

BUG Rating

B0 U3 G2
