T8-12-36GC-840-SE-BYP-DIM

Spec Sheet Dimmer Compatibility List Instructions Family Spec Sheet Spec Sheet

Replacement for conventional fluorescent T8 and T12 linear tubes

Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Works with non-shunted sockets ONLY

NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations)

For use with compatible 0-10V dimming systems

View Technical Specs

View Price & Availability

Performance

Watts	12W
Color Temp	4000K
Lumens	1,550 lm
Efficacy	129
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	N/A
Power Factor	N/A
Flicker	N/A
THDi	N/A

Dimensions

Weight: 0.4 lbs

Technical Specifications

Performance

Product Type

Linear Tube

Wattage Equivalency

25W Fluorescent

Input Wattage

12W

Lumens

1,550lm

Efficacy

129lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Length

3 ft

Electrical

THD

≤25%

Power Factor

>0.9

Dimmable

Yes, dimmable down to 10% on compatible 0-10V dimming systems. See Dimmer Compatibility List.

Input Voltage

120-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

101mA

Input Current @ 208V (mA)

58mA

Input Current @ 240V (mA)

53mA

Input Current @ 277V (mA)

46mA

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

Flicker

≤5%

LED Characteristics

Beam Angle

160°

Color Temperature

4000K

Color Accuracy (CRI)

≥80 CRI

R9 Value

High color performance with R9 greater than 0

Color Consistency

<5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Installation Method

UL Type B, Ballast Bypass

Base Type

G13

Construction

Shape

Finish

White

Endcap Material

Plastic

Enclosure Material

Glass w/ Polyethylene Terephthalate (PET)

Lens Finish

Frosted

Compliance

Listings

UL Classified, UL Recognized

ETL Listed

Environment

Suitable for use indoors in dry and damp environments.

Fixture Rating

Suitable for use in enclosed fixtures.
Suitable for use in open fixtures.

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

Certification Model Number

T10284(T8-12-36GC-840-SE-BYP-DIM)

California Title 20 Compliant

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

NSF Listed

Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
