SM-9R-W/EMBB
Dimensions
Weight: 1.4 lbs
Technical Specifications
Performance
Product Type
Surface Mount Battery Backup
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Electrical
THD
<20%
Power Factor
0.9
Input Voltage
100-277V
Operating Frequency
60 Hz
Input Current @ 120V (mA)
60mA
Input Current @ 208V (mA)
100mA
Emergency Operation
90 minutes
Battery Type
Lithium Ion
Battery Recharge Time
24 hours
Discharge Temperature
32°F to 122°F (0°C to 50°C)
Storage Temperature
-4°F to 77°F (-20°C to 25°C)
Storage Shelf Life
1-year
Lightcloud
Operating Temperature
41°F to 104°F (5°C to 40°C)
Installation
Mounting
Surface Mount
Construction
Size
9"
Shape
Round
Finish
White
Enclosure Material
Metal
Trim Style
Smooth
UV Protection
No
Compliance
Listings
UL Recognized
Environment
Suitable for use indoors in dry and damp environments.
IC Rated
No
Certification Model Number
SM-9R-W/EMBB
California Title 20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
No
California Energy Commission (CEC) Status
Lawful for Sales in California
Other
Compatible Products
Compatible with select Surface Mount Downlights, see complete Downlight Accessory Compatibility Guide.
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
