SENSE/PIR/W/LCB
SENSE/PIR/W/LCB
- Completely wireless occupancy sensor
- Easily mount to a wall, ceiling or place it on a shelf
- Adjustable base to expand the detection area
- Passive infrared technology and daylight sensing
- Battery operated, 3-year lifespan
Dimensions
Weight: 0.2 lbs
Technical Specifications
Performance
Product Type
Wireless Sensor
Description
This Wireless Occupancy Sensor is a passive infrared motion detector used to switch lights on/off or dim. Compatible with all Lightcloud Blue-enabled lamps and luminaires and easy to configure using the Lightcloud Blue mobile app. Choose between occupancy/vacancy, adjust sensitivity levels, timeouts, and actions all from the mobile app.
Lightcloud
Lightcloud Blue
Lightcloud Blue is a Bluetooth Mesh wireless lighting control system that allows you to control RAB's various compatible devices. With RAB's patented Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system's reach.
DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
Learn more at www.lightcloud.com.
DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
Learn more at www.lightcloud.com.
Gateway Required
No
Communication Protocol
Bluetooth Mesh
Range
Up to 60 ft between standard building materials. Building materials such as brick, concrete, and steel construction may require additional Lightcloud Blue devices to extend around an obstruction.
Up to 200 ft clear line of sight (varies by device).
Up to 200 ft clear line of sight (varies by device).
Spacing Criteria
Lightcloud Blue devices should be placed within the specified range to communicate within the Bluetooth Mesh network.
Factory Reset
Method 1: Delete from App
Open the app and access the device settings for the paired device. Be sure that the sensor is awake and select 'Delete'.
Method 2: Manual Press and hold the reset button on the back of the sensor near the battery compartment for 5 seconds or until the indicator light on the front of the sensor flashes blue.
Open the app and access the device settings for the paired device. Be sure that the sensor is awake and select 'Delete'.
Method 2: Manual Press and hold the reset button on the back of the sensor near the battery compartment for 5 seconds or until the indicator light on the front of the sensor flashes blue.
Electrical
Battery Type
Lithium CR2 (included in package)
Battery Lifespan
3-years
Operating Temperature
14°F to 122°F (-10°C to 50°C)
Detection Angle
120° to 150°
Max Mounting Height
8 ft to 12 ft
Detection Range
20 ft diameter mounted at 9 ft
Sensor Settings
Sensor Technology
Passive Infrared (PIR)
Default Setting
Uncommissioned State:
Motion Sensitivity: High
Brightness when triggered: 100%
Hold time: 1 minute
Standby to dim: 20%
Standby time: 1 minute
When vacant: Off
Commissioned State:
Motion Sensitivity: High
Brightness when triggered: Last on status
Hold time: 20 minutes
When vacant: Off
Motion Sensitivity: High
Brightness when triggered: 100%
Hold time: 1 minute
Standby to dim: 20%
Standby time: 1 minute
When vacant: Off
Commissioned State:
Motion Sensitivity: High
Brightness when triggered: Last on status
Hold time: 20 minutes
When vacant: Off
Sensing Type
Occupancy or Vacancy
Occupied Actions
On or On at a Dim Level
Vacant Options
Off or On at a Dim Level
Occupancy Timeout
1 minute to 240 minutes
Daylight Sensing
The sensor will determine to trigger the light(s) on or not based on the daylight threshold level set in the Lightcloud Blue mobile app.
Daylight Threshold
150 lux to 1500 lux
Installation
Mounting
(3) mounting screws and base adhesive included in package.
Construction
Shape
Cube
Finish
White
Compliance
Environment
Suitable for use in dry and damp indoor environments
California Energy Commission (CEC) Status
Lawful for Sales in California
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
DLC NLC Listed
This product is on the Design Lights Consortium (DLC) Network Lighting Controls (NLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
DLC system - N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
Other
Compatible Products
Any Lightcloud Blue-enabled lamp or luminaire
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Buy American Act Compliance
RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
