PLL-14-850-DIR

Spec Sheet Ballast Compatibility List Instructions FCC Caution Spec Sheet

PLL-14-850-DIR

Replaces 36W twin tube CFL 2G11 Lamps

Ballast Compatible. Directly Compatible with Most Existing Electronic CFL Ballasts.

Compatible with 2G11 (4-pin CFL) installations

50,000 hour Lifespan

Environmentally friendly, no mercury used

UL Listed

Rated for use in enclosed and open fixtures in dry or damp locations

5 Year No Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	14W
Color Temp	5000K
Lumens	2,000 lm
Efficacy	118
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.12A
208V	0.07A
240V	0.06A
277V	0.05A
Input Watts	14.5W

Dimensions

Weight: 0.3 lbs

Technical Specifications

Performance

Product Type

Compact

Input Wattage

14.5W

Lumens

2,000lm

Efficacy

118lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Wattage Equivalency

36W CFL

Electrical

THD

20%

Power Factor

0.9

Dimmable

Not suggested for dimming applications

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Input Voltage

120-277V

Operating Frequency

50/60Hz

Compliance

UL Listed

Suitable for damp locations

Enclosed Fixtures

Suitable for use in enclosed fixtures

LED Characteristics

Color Temperature

5000K

Color Accuracy (CRI)

≥80 CRI

Beam Angle

120°

Construction

Bulb Shape

PLL 16in

Endcap Material

Polycarbonate

Enclosure Material

Glass & Polycarbonate

Installation

Base Type

2G11

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
