PAR38-12.5-830-25D-DIM
PAR38-12.5-830-25D-DIM
- Energy efficient replacement for incandescent and halogen PAR lamps
- Constructed from durable materials which lowers risk of breakage
- Rated for use in enclosed and open fixtures in wet locations
- Single optic and full face lens for precise beam angle control
Performance
| Watts | 12W |
| Color Temp | 3000K |
| Lumens | 1,200 lm |
| Efficacy | 96 |
| Color Accuracy | 80 CRI |
| L70 Lifespan |
| Type | |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 12.5W |
Dimensions
Weight: 0.6 lbs
Technical Specifications
Performance
Product Type
PAR38
Description
This dimmable, PAR38 is a perfect replacement for legacy halogen lamps. This lamp offers >80 CRI, wet rated, and great for use outdoors.
Wattage Equivalency
120W Halogen
Input Wattage
12.5W
Lumens
1,200lm
Efficacy
96lm/W
L70 Lifespan
25,000-Hour LED lifespan based on IES LM-70 results
LED Characteristics
Beam Angle
26-degree
Color Accuracy (CRI)
≥80 CRI
R9 Value
High color performance with R9 greater than or equal to 0
Color Consistency
<6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Electrical
THD
<80%
Power Factor
>0.7
Dimmable
Yes, TRIAC/ELV
See Dimmer Compatibility List
See Dimmer Compatibility List
Input Voltage
120V
Operating Frequency
60 Hz
Operating Temperature
-13°F to 113°F (-25°C to 45°C)
Installation
Base Type
E26 Edison
Construction
Finish
White
Shape
PAR38
Endcap Material
Nickel-Aluminum
Enclosure Material
Plastic
Lens
Single optic and full face lens for precise beam angle control
Compliance
Listings
UL Listed
Environment
Suitable for use in indoor and outdoor application in dry, damp, and wet environments
Fixture Rating
Suitable for use in enclosed fixtures
T20 Compliant
Not compliant
California Title 24 JA8 Compliant
Not Compliant
California Energy Commission (CEC) Status
Not Lawful for Sales in California
NSF Listed
No
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Other
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
