Technical Specifications
Sensor Settings
Default Setting
Brightness: 100%
Hold Time: 20 Minutes
Daylight: Disabled
Sensitivity: 100%
Stand-by Dimming Level: 20%
Hold Time: 20 Minutes
Daylight: Disabled
Sensitivity: 100%
Stand-by Dimming Level: 20%
Operating Voltage
12V DC
Operating Current
≤25mA
Output
Dim/0-10V
Microwave Frequency
5.8GHz±75MHz
Microwave Power
<0.3mW
Stand-by Power
≤0.5W
Detection Area
25%/50%/75%/100%
Hold Time
5s/30s/1min/3min/5min/10min/20min/30min
Daylight Threshold
2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable
Stand-by Period
0s/10s/30s/1min/5min/10min/30min/+∞
Stand-by Dimming Level
10%/20%/30%/50%
Operating Temperature
-20°C~+60°C
Maximum Mounting Height
13 ft
Max Detection Range
10 ft diameter at 32 ft
Motion Detection
0.5~1.5m/s
Lux On-Off
Adopted dual PD technology. HAZMVS is able to differenciate artificial light brightness from natural light after installed inside.
