ECOMBO-CH
Dimensions
Weight: 5.5 lbs
Technical Specifications
Performance
Product Type
Exit Combo New York City Approved
Description
New York City-approved exit sign combo with 90-minute emergency battery backup unit.
Input Power (W)
5.2W @120V; 6.2W @277V
Lumens
65lm
Lumens (per fixture)
195lm
Electrical
Power Factor
0.72@120V; 0.6@277V
Input Voltage
Dual 120/277 Voltage
Operating Frequency
50/60Hz
Input Current @ 120V (mA)
60mA
Input Current @ 277V (mA)
40mA
Maximum Output Current (Amps)
0.16A
Maximum Output Wattage
1.5W
Dual Voltage Circuit Operation
No
Operating Temperature
32°F to 122°F (0°C to 50°C)
Emergency Illumination
90 minutes
Battery Type
Nickel Cadmium
Battery Voltage
9.6V
Recharge Time Required
24-hours
Battery Operating Temperature
0°F to 50°F (32°C to 122°C)
Storage Temperature
68°F to 86°F (20°C to 30°C)
Storage Shelf Life
3 years before the initial charge. 5 years after initial charge.
Self Diagnostics
No, manual test only
Remote Test Switch
No
Emergency Backup
Battery Backup
Yes
Installation
Mounting Method
Back/End
Mounting Type
Wall/Ceiling Mount
Maximum Mounting Height (ft.)
10 ft
Spacing Criteria for Emergency Egress
26 ft on center assuming 7.5 ft mounting height with egress path 3 ft out
Cold Weather Rated
No
Construction
Shape
Rectangle
Housing Material
Sheet Metal
Housing Color
White
Panel Material
Sheet Metal
Panel Color
White
Letter Color
Red
Number of Faces
Universal Single/Double Face
Arrow Direction
Field installable chevrons included
Sign Format
Stencil
Remote Capacity
Yes
No. of Heads
2-Lamp Heads
Head Shape
Square
Remote Head Power (W)
1.5W
Remote Head Lumens (lm)
65lm
Remote head Lumens (per fixture)
195lm
Remote Heads Replaceable
Yes
Remote Power (W) Capacity
1.5W
Compliance
Listings
UL924 Listed
Environment
Suitable for indoor use in dry and damp environments
IP Rating
Indoor
Certification Model Number
PRLEDCNYXTE3RW43
T20 Compliant
Not compliant
California Title 24 JA8 Compliant
Not applicable
California Energy Commission (CEC) Status
Lawful for Sales in California
City Compliance
New York City Approved
FCC
Complies with Part 15 of the FCC Rules
Other
Compatible Products
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
