WBLED18N/PCS

18 Watt LED architectural wall sconce

Companion fixture to RAB BLED Round and Square Bollard

Durable construction and vandal-resistant polycarbonate lens

100,000-hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	18W
Color Temp	4000K (Neutral)
Lumens	2,058 lm
Efficacy	117.6 lm/W
Color Accuracy	72 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.24A
208V
240V
277V
Input Watts	17.5W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 14.0 lbs

Technical Specifications

Electrical

Driver

Constant Current, Class 2, 100-277V, 50/60 Hz, 4kV Surge Protection, 700mA, 120V: 0.24A, 208V: 0.18A, 240V: 0.15A, 277V: 0.12A

THD

8.23% at 120V, 7.79% at 277V

Power Factor

99% at 120V, 94.8% at 277V

Photocell

120V Swivel photocell included. Photocell is only compatible with 120V.

Compliance

UL Listed

Suitable for wet locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Color Consistency

5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Optical

BUG Rating

B1 U3 G2

Construction

Cold Weather Starting

The minimum starting temperature is -40°C (-40°F)

Thermal Management

Cast aluminum Thermal Management system for optimal heat sinking. The BLED is designed for cool operation, maximum efficiency and long life by minimizing LED junction temperature.

Housing

Reinforced Die-cast Aluminum

Lens

Polycarbonate lens

Reflector

Vacuum-metalized polycarbonate

Gaskets

High-temperature silicone gaskets seal out moisture gaskets seal out moisture

Finish

Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Die-cast aluminum wall bracket with five (5) 1/2" conduit openings with plugs

Other

Patents

The design of WBLED is protected by patents in US, Canada & China

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
