TBLED3T32RG/D10/7PRS
DISCONTINUED
TBLED3T32RG/D10/7PRS
- IP66 Rated
- Industry-leading 5G vibration rating per ANSI C136.31
- ANSI C136.41 7-pin receptacle, compatible with wireless control systems
- 100,000-Hour LED lifespan
- 10-Year, limited warranty
Performance
| Watts | 32W |
| Color Temp | 5000K (Cool) |
| Lumens | 3,743 lm |
| Efficacy | 117.7 lm/W |
| Color Accuracy | 73 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.27A |
| 208V | 0.17A |
| 240V | 0.15A |
| 277V | 0.13A |
| Input Watts | 31.8W |
Dimensions
Weight: 9.2 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Minimum of 75° supply conductors.
IP Rating
Ingress protection rating of IP66 for dust and water
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Construction
IES Classification
The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It has greater streetside (transverse) throw, allowing the light to project outward and fill the area.
Vibration Rating
Industry-leading 5G vibration rating per ANSI C136.31
Ambient Temperature
Suitable for use in up to 40°C (104°F)
Cold Weather Starting
The minimum starting temperature is -40°C (-40°F)
Thermal Management
Superior thermal management design with external Air-Flow fins provides maximum operational life, even in high ambient temperature environments
Housing
Die-cast aluminum housing with polycarbonate driver cover
Lens
Clear acrylic lens with integrated optics
Gaskets
High-temperature silicone gaskets
Effective Projected Area
EPA = 0.7
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
LED Characteristics
LEDs
Multi-chip, high-output, long-life LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Electrical
Drivers
Constant Current, Class 2, 100-277V, 50-60Hz, 120V: 0.27A, 208A: 0.17A, 240A: 0.15A, 277V: 0.13A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
7-Pin Receptacle with Shorting Cap
ANSI C136.41 7-pin receptacle, compatible with wireless control systems
Surge Protection
10kV
Optical
BUG Rating
B1 U0 G1
Installation
Mounting
Fits most standard roadway upsweep arms. Adaptor brackets supplied fit 1", 1 1/4", 1 1/2" and 2" pipe arms. Fixture can be tilted at the following angles -5°, -2.5°, 0°, +2,5°, +5°.
Performance
Wattage Equivalency
Equivalent to 70W Metal Halide/50W HPS
