T8-7.5-24G-840-EXT

Replacement for conventional fluorescent T8 and T12 linear tubes

Dedicated External driver must be paired together with RAB tubes

Can be installed using single ended or double ended wiring method

Works with non-shunted sockets AND shunted sockets.

50,000 hour Lifespan

Rated for use in enclosed and open fixtures in dry or damp locations

Diffused frosted lens will maintain the same light quality over time

Instant on full brightness

Low Flicker less than 1%

UL Classified, DLC Listed

View Technical Specs

View Price & Availability

Performance

Watts	7W
Color Temp	4000K (Cool White)
Lumens	1,200 lm
Efficacy	160 lm/W
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277
Power Factor	>0.9
Flicker	Depend on Type C Driver
THDi	N/A

Dimensions

Weight: 0.3 lbs

Technical Specifications

Performance

Product Type

Linear

Input Wattage

7.5W

Lumens

1,200lm

Efficacy

133lm/W

L70 Lifespan

50,000 Hours

Wattage Equivalency

17W Fluorescent

Construction

Material

Glass

Shape

Nominal Length

2 ft

Finish

Frosted

For Use Outdoors in Open Fixtures

LED Characteristics

Color Temperature

4000K Cool White

Color Accuracy (CRI)

80 CRI

Beam Angle

220°

Installation

Base Type

G13

Installation Type

Type C, External Driver

Electrical

THD

<25%

Power Factor

>0.9

Operating Temperature

-13°:F to 113°F(-25°C to 45°C)

Dimming

Yes with 0-10V dimmer. See Dimmer Compatibility List.

Input Voltage

120-277V AC

Operating Frequency

50/60Hz

Flicker

Depends on Type C Driver

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

UL Recognized

Yes

NSF Listed

Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.

California Energy Commission (CEC) Status

Lawful for Sales in California

2 Lamp Application

DLC Model Number: T10064
DLC ID Number: PLRWHPDEWRQL

3 Lamp Application

DLC Model Number: T10064-3
DLC ID Number: PLSOMWKJRSUU

4 Lamp Application
