T8-15-U6GC-835-EXT
T8-15-U6GC-835-EXT
- Compatible with RAB Type C T8 LED Lamps only
- Meets FCC Part 15 (Class B) Consumer Limits
- Short Circuit Overload and Open Load Protection
- Suitable for Dry and Damp Locations
- UL8750 Recognized Component
- Dimmable with 0-10V Dimmer
- Maximum Case Temperature: 75°C/167°F
- Input Frequency: 50/60 Hz
- THD: < 20%
- Type P
- Output Class 2
Performance
| Watts | 15W |
| Color Temp | 3500K |
| Lumens | 2,100 lm |
| Efficacy | 127 |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 50,000 Hours |
| Input Voltage | Driver Dependent |
| Power Factor | 0.9 |
| Flicker | N/A |
| THDi | 20 |
Dimensions
Weight: 0.6 lbs
Technical Specifications
Performance
Product Type
Linear
Input Wattage
15W
Lumens
2,100lm
Efficacy
127lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Compliance
UL Listed
Suitable for damp locations
Enclosed Fixtures
Suitable for use in enclosed fixtures
Certification Model Number
T10338(T8-15-U6GC-835-EXT)
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
LED Characteristics
Color Temperature
3500K
Color Accuracy (CRI)
≥80 CRI
Beam Angle
160°
Construction
Shape
U6
Endcap Material
Polycarbonate
Enclosure Material
Glass & Polycarbonate
Installation
Base Type
G13
Electrical
THD
20%
Power Factor
0.9
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Input Voltage
Driver Dependent
Operating Frequency
50/60Hz
Dimming
Yes with 0-10V dimmer. See Dimmer Compatibility List.
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
