T5HO-25-48G-840-SE-BYP

Spec Sheet Photometrics Report Instructions FCC Caution Family Spec Sheet Spec Sheet

Replacement for conventional fluorescent tubes

Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Single ended wiring method

50,000 hour Lifespan

Rated for use in enclosed and open fixtures in dry or damp locations

Diffused frosted lens will maintain the same light quality over time

Instant on full brightness

Environmentally friendly, no mercury used

NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations)

UL Classified

View Technical Specs

View Price & Availability

Performance

Watts	25W
Color Temp	4000K
Lumens	3,500 lm
Efficacy	140
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277V
Power Factor	>0.9
Flicker	N/A
THDi	<20%

Dimensions

Weight: 0.4 lbs

Technical Specifications

Performance

Product Type

Linear

Input Wattage

25W

Lumens

3,500lm

Efficacy

140lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Wattage Equivalency

F54T5/HO

LED Characteristics

Color Accuracy (CRI)

Color Temperature

4000K

Beam Angle

180°

Construction

Nominal Length

4 ft

Shape

Enclosure Material

Glass

Housing Finish

Aluminum

Lens Finish

Frosted

Installation

Base Type

Installation Method

UL Type B, Ballast Bypass - Single Ended Wire

Electrical

THD

≤20%

Power Factor

>0.9

Operating Temperature

-20°C to 45°C

Input Voltage

120-277V

Operating Frequency

50/60Hz

Dimming

Other

Technology EQ

Fluorescent

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Compliance

Listings

UL Classified, UL Recognized

Environment

Damp / Enclosed

NSF Listing

NSF/ANSI Standard 2 - Food Equipment (non-contact), Splash Zone, and Non-Food Zone. (Not for Direct Food Zone without additional fixture considerations)

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Certification Model Number

T10182 (T5HO-25-48G-840-SE-BYP)

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
