T5HO-16-36G-840-SD-BYP

Spec Sheet IES File LM79 Instructions FCC Caution Spec Sheet EZ Layout

Replacement for conventional fluorescent T5HO tubes

Integral Driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Single and double ended wiring method works with both shunted and non-shunted sockets

Environmentally friendly, no mercury used

NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations)

View Technical Specs

View Price & Availability

Performance

Watts	16W
Color Temp	4000K
Lumens	2,100 lm
Efficacy	131
Color Accuracy	82 CRI
L70 Lifespan	50,000 Hours

Input Voltage	120-277V
Power Factor	>0.9
Flicker	N/A
THDi	<25%

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.3 lbs

Technical Specifications

Performance

Product Type

Linear Tube

Wattage Equivalency

39W T5HO Fluorescent

Input Wattage

16W

Lumens

2,100lm

Efficacy

131lm/W

Lifespan

50,000-Hour LED lifespan based on IESlm-70 results

Electrical

THD

<25%

Power Factor

>0.9

Dimmable

Yes, although this lamp is not suggested for dimming applications

Input Voltage

120-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

250mA

Input Current @ 208V (mA)

65mA

Input Current @ 240V (mA)

75mA

Input Current @ 277V (mA)

65mA

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

LED Characteristics

Color Temperature

4000K

Color Accuracy (CRI)

82 CRI

R9 Value

High color performance with R9 greater than 0

Color Consistency

<5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Installation Method

UL Type B

Base Type

Construction

Nominal Length

3 ft

Shape

T5HO

Endcap Material

Metal

Enclosure Material

Glass

Lens Finish

Frosted

Compliance

Listings

UL Recognized, UL Classified

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in enclosed fixtures

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Certification Model Number

T20063(T5HO-16-36G-840-SD-BYP)

California Energy Commission (CEC) Status

Lawful for Sales in California

NSF Listed

Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

Other

Compatible Products

See Dimmer and Ballast compatibility lists.

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
