T5HE-13-48G-850-DIR
T5HE-13-48G-850-DIR
- Direct Replacement for conventional fluorescent tubes
- Easy to install plug and play that requires no rewiring, no tools, no instructions
- 50,000 hour Lifespan
- Rated for use in enclosed and open fixtures in dry or damp locations
- Diffused frosted lens will maintain the same light quality over time
- Compatible with most program start electronic T5 ballasts, Please check Compatibility List.
- Instant on full brightness
- Environmentally friendly, no mercury used
- NSF Listed: NSF/ANSI Standard 2 - Food Equipment - Splash Zone (Not for Direct Food Zone without additional fixture considerations
- UL Listed
- Compatible with RAB specified 0-10V dimming system
Performance
| Watts | 13W |
| Color Temp | 5000K |
| Lumens | 2,000 lm |
| Efficacy | 154 |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 50,000 Hours |
| Input Voltage | 120-277V |
| Power Factor | >0.9 |
| Flicker | N/A |
| THDi | <20% |
Dimensions
Weight: 0.4 lbs
Technical Specifications
Performance
Product Type
Linear
Input Wattage
13W
Lumens
2,000lm
Efficacy
154lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
F28T5
LED Characteristics
Color Accuracy (CRI)
80
Color Temperature
5000K
Construction
Nominal Length
4 ft
Shape
T5
Enclosure Material
Glass
Housing Finish
Aluminum
Lens Finish
Frosted
Installation
Base Type
G5
Installation Method
UL Type A, Plug and Play
Electrical
THD
≤20%
Power Factor
>0.9
Operating Temperature
-20°C to 45°C
Input Voltage
120-277V
Operating Frequency
50/60Hz
Dimming
Yes with 0-10V dimmer + ballast. See Dimmer Compatibility List.
Other
Technology EQ
Fluorescent
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Compliance
Listings
UL Listed
Environment
Damp / Enclosed
NSF Listing
NSF/ANSI Standard 2 - Food Equipment (non-contact), Splash Zone, and Non-Food Zone. (Not for Direct Food Zone without additional fixture considerations)
Certification Model Number
T10155(T5HE-13-48G-850-DIR)
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
