STRING17-100
STRING17-100
- Each LED bulb delivers 1200 lumens for a total of 12,000 lumens per fixture
- Durable 100ft. SPT-2W 18/2 AWG power cord, with integrated hanging hook on each lamp
- ANTI-UV protection for sun exposure and IP65 rated
- Linkable strands up to 400W; a total of 4 fixtures
- 120V AC input voltage
Performance
| Watts | 100W |
| Color Temp | 5000K |
| Lumens | 12,000 lm |
| Efficacy | 120 |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 50,000 Hours |
| Input Voltage | 120V |
| Power Factor | 0.9 |
| Flicker | 30% |
| THDi | N/A |
Dimensions
Weight: 4.8 lbs
Technical Specifications
Performance
Product Type
LED Temporary String Light
Description
Upgrade traditional work lights with efficient, portable LED string lights.
Wattage Equivalency
300W Incandescent
Input Wattage
100W
Lumens
12,000lm
Efficacy
120lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Electrical
Driver
Constant Current
Power Factor
0.5
Dimmable
No
Input Voltage
120V
Operating Frequency
60 Hz
Input Current @ 120V (mA)
1,430mA
Operating Temperature
-40°F to 104°F (-40°C to -40°C)
Flicker
30%
Sensor Settings
Surge Protection
1 kV
LED Characteristics
Beam Angle
120°
Color Temperature
5000K
Color Accuracy (CRI)
>80 CRI
Color Consistency
<7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Installation
Mounting
Integrated hanging hook
Base Type
SPT-2W 18/2AWG power cord, high-impact design ANSI 2-prong plug and receptacle with weatherproof cover. No ground required; housing is made of polycarbonate material
Linkable
Linkable strands up to 400W
Construction
Lamp Shape
Oval lamp with frosted lens
Finish
Orange
Enclosure Material
Constructed from frosted, shatter-resistant polycarbonate
Compliance
ETL Listed
This product has been tested by Intertek and found in compliance with accepted national standards.
Environment
Suitable for use indoors and outdoors in dry, damp, or wet environments.
Fixture Rating
Suitable for use in enclosed fixtures.
Suitable for use in open fixtures.
Suitable for use in open fixtures.
IP Rating
IP65
Energy Star Approved
No
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Certification Model Number
STRING17-100
California Title 20 Compliant
No
California Title 24 JA8 Compliant
No
California Energy Commission (CEC) Status
Lawful for Sales in California
NSF Listed
No
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
Other
3-Year Limited Warranty
The RAB 3-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty
