SLIM15YW
34W 3000K
- Selectable Wattages
- Full cutoff
- 120V
- 5-Year, limited warranty
Performance
| Watts | 34/25/13W |
| Color Temp | 3000K |
| Lumens | 3,638/2,760/1,467 lm |
| Efficacy | 105.7/109.1/120 lm/W |
| Color Accuracy | 85/85/85 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.30A/0.21A/0.11A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 34.4/25.3/13.1W |
Dimensions
Weight: 2.0 lbs
Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
34/25/13 (factory default 34W)
34/25/13 (factory default 34W)
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
LUNA
This product has received the Design Lights Consortium's LUNA listing. Designed to meet LUNA 5.1 requirements.
LUNA Product Code: S-HSGKDV
LUNA Product Code: S-HSGKDV
Performance
Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
34W: Replaces up to 150W Metal Halide (MH) or 100W High Pressure Sodium (HPS)
25W: Replaces up to 100W Metal Halide (MH) or 100W High Pressure Sodium (HPS)
13W: Replaces up to 70W Metal Halide (MH) or 50W High Pressure Sodium (HPS)
25W: Replaces up to 100W Metal Halide (MH) or 100W High Pressure Sodium (HPS)
13W: Replaces up to 70W Metal Halide (MH) or 50W High Pressure Sodium (HPS)
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Consistency
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Construction
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 104°F (40°C)
Housing
Precision die-cast aluminum / Polycarbonate
Lens
Polycarbonate lens
Reflector
Mirror finish on polycarbonate
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Hinged wiring access and conduit entries on the back sides, top and bottom make installation a snap
Electrical
Driver
Integrated driver, 60 Hz, 120V:
34W: 0.30A
25W: 0.21A
13W: 0.11A
34W: 0.30A
25W: 0.21A
13W: 0.11A
THD
12.56% at 120V
Power Factor
99.1% at 120V
Surge Protection
4 kV
Optical
BUG Rating
34W: B1 U0 G1
25W: B1 U0 G1
13W: B1 U0 G0
25W: B1 U0 G1
13W: B1 U0 G0
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
