SBR10
SBR10
- True UL 924 certified LED Retrofit tube that is hardwired 24/7 to main power
- Bypass the ballast, driver integrated directly into the lamp body
- 3 selectable color temperatures
- Backup battery provides up to 200-minutes of emergency illumination
- Easy to install, simply remove existing sockets from fixture and wire tube directly
Performance
| Watts | 14W |
| Color Temp | 3500/4000/5000K |
| Lumens | 1,750/1,800,1,800 lm |
| Efficacy | 121/124/124 lm/W |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 14.5W |
Dimensions
Weight: 1.2 lbs
Technical Specifications
Performance
Product Type
Emergency Linear Tube
Description
The SBR10 Tube is a UL Type B T8 tube featuring an innovative design that incorporates a rechargeable battery into a tube format, ensuring a permanent installation that cannot be easily tampered with or removed accidentally.
Wattage Equivalency
32W Fluorescent
Input Wattage
14.5W
Lumens
3500K @ 1,750lm; 4000K @ 1,800lm; 5000K @ 1,800lm
Efficacy
3500K @ 121lm/W; 4000K @ 124lm/W; 5000K @ 124lm/W
Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
\
Electrical
THD
20%
Power Factor
>0.9
Dimmable
Yes, dimmable down to 15-20% on compatible TRIAC/ELV dimming systems. See Dimmer Compatibility List.
Input Voltage
120-277V
Operating Frequency
50/60Hz
Input Current @ 120V (mA)
121mA
Input Current @ 208V (mA)
70mA
Input Current @ 240V (mA)
60mA
Input Current @ 277V (mA)
52mA
Battery Operating Temperature
32°C to 104°C (0°F to 40°F)
Flicker
50%
Emergency Operation
90 minutes @ 0° ambient temperature; 200-minutes @ 77°F (25°C)
Emergency Lumens
400lm (3.5W)
Battery Recharge Time
24 hours @ 0deg; ambient temperatureours
LED Characteristics
Beam Angle
140°
Color Temperature
3500/4000/5000K
Color Accuracy (CRI)
≥80 CRI
R9 Value
High color performance with R9 greater than 0
Color Consistency
<7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability
LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Installation
Installation Method
UL Type B, Ballast Bypass
Base Type
Hardwired
Construction
Length
4 ft
Shape
T10
Finish
White
Endcap Material
Polycarbonate
Enclosure Material
Aluminum & Polycarbonate
Lens Finish
Frosted
Compliance
Listings
UL Recognized, UL Classified
Environment
Suitable for use indoors in dry and damp environments.
Fixture Rating
Suitable for use in enclosed fixtures
Certification Model Number
BT01(SBR10)
California Title 20 Compliant
No
California Title 24 JA8 Compliant
No
California Energy Commission (CEC) Status
Lawful for Sales in California
NSF Listed
Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones. Tube guard required in open fixtures.
Rohs
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
