R6S10850120WB
  • Deep regressed lens
  • No recessed housing or J-box required
  • New construction or retrofit applications
  • UL wet location rated
  • Spring loaded retention clips
  • Robust, die cast aluminum construction
  • IC and airtight rated
  • 5-Year, No-Compromise Warranty
View Technical Specs
Performance
Watts 10W
Color Temp
Lumens 1,000 lm
Efficacy 100 lm/W
Color Accuracy
L70 Lifespan
Type Constant Current
120V
208V
240V
277V
Input Watts 10W
Dimensions
Link to Dimension Drawing
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
Energy Star Approved
ENERGY STAR® Version 2.2 Certified
Certification Model Number
DLR0095
Energy Star ID
2350002
Electrical
Dimming Driver
TRIAC compatible dimmer with dimming as low as 5%. See dimmer compatibility guide here.
Remote Driver
Die-cast metal driver / junction box with a hinged cover.
Listed for 12AWG and 14AWG conduit.
Includes two metal knockouts for wiring.
Quick connectors included.
Plenum rated cable connector to connect from module to remote driver box.
