R20-7-827-DIM
R20-7-827-DIM
- Energy efficient replacement for incandescent and halogen reflector lamps
- Constructed from durable plastic which lowers risk of breakage
- Rated for use in enclosed and open fixtures in dry or damp locations
- Frosted lens produces smooth diffuse light
- Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs
- ENERGY STAR Compliant
- Dimmable with common dimmer types (see Dimmer Compatibility List)
Performance
| Watts | 7W |
| Color Temp | 2700K (Soft White) |
| Lumens | 525 lm |
| Efficacy | 75 lm/W |
| Color Accuracy | 80 CRI |
| L70 Lifespan | 25,000 Hours |
| Input Voltage | 120V |
| Power Factor | 0.9 |
| Flicker | <30% |
| THDi | N/A |
Dimensions
Weight: 0.2 lbs
Technical Specifications
Performance
Product Type
Reflector
Input Wattage
7W
Lumens
525lm
Efficacy
75lm/W
L70 Lifespan
25,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
50W
LED Characteristics
Color Accuracy (CRI)
80
Color Temperature
2700K
Beam Angle
110°
Electrical
Power Factor
>0.9
Dimmable
Yes, down to 10%
Input Voltage
120V
Operating Temperature
-20°C to 40°C
Construction
Bulb Shape
R20
Enclosure Material
Plastic
Housing Finish
White
Lens Finish
Frosted
Installation
Base Type
E26 Edison
Other
Technology EQ
Incandescent
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Compliance
UL Listed
Yes
Environment
Damp / Enclosed
Rohs
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
\
