R20-5-922/30-WGD
R20-5-922/30-WGD
- Produces rich and vibrant colors >90CRI
- Energy efficient replacement for incandescent and halogen Reflector lamps
- Constructed from durable plastic which lowers risk of breakage
- Rated for use in enclosed and open fixtures in dry or damp locations
- Frosted lens produces smooth diffuse light
- Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs
- ENERGY STAR Compliant, Title 20 Compliant
- Smooth warm to dim transition between 2200K to 3000K color temperatures
- Uniform dimming down to 10% (See Dimmer Compatibility List)
Performance
| Watts | 5W |
| Color Temp | 2200/3000K |
| Lumens | 500 lm |
| Efficacy | 90.9 |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 15,000 Hours |
| Input Voltage | 120V |
| Power Factor | 0.7 |
| Flicker | N/A |
| THDi | 62.9 |
Dimensions
Weight: 0.1 lbs
Technical Specifications
Performance
Product Type
Reflector
Input Wattage
5.5W
Lumens
500lm
Efficacy
90.9lm/W
L70 Lifespan
15,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
40W Halogen
Compliance
UL Listed
Suitable for damp locations
Enclosed Fixtures
Suitable for use in enclosed fixtures
LED Characteristics
Color Temperature
2200/3000K
Color Accuracy (CRI)
>90 CRI
Beam Angle
110°
Electrical
THD
62.90%
Power Factor
0.7
Dimmable
Yes
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Input Voltage
120V
Operating Frequency
60 Hz
Construction
Shape
R20
Endcap Material
Polycarbonate
Enclosure Material
Plastic
Installation
Base Type
E26 Edison
Other
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
