PLS-5.2-H-850-HYB
PLS-5.2-H-850-HYB
- Replaces 13W CFL Lamps
- Plug and Play on existing magnetic CFL ballasts or can be wired directly to line voltage without need for an external driver or ballast
- Compatible with Gx23 base installations
- 50,000 hour Lifespan
- Environmentally friendly, no mercury used
- UL Classified
- Rated for use in enclosed and open fixtures in dry or damp locations
- 5 Year No Compromise Warranty
Performance
| Watts | 5W |
| Color Temp | 5000K |
| Lumens | 600 lm |
| Efficacy | 109.1 |
| Color Accuracy | 80 CRI |
| L70 Lifespan |
| Input Voltage | 120-277V |
| Power Factor | >0.9 |
| Flicker | 50% |
| THDi | 20% |
Dimensions
Technical Specifications
Performance
Product Type
Compact
Input Wattage
5.5W
Lumens
600lm
Efficacy
109.1lm/W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
11W CFL
LED Characteristics
Color Accuracy (CRI)
80 CRI
Beam Angle
120°
Color Temperature
5000K
Construction
Material
Polycarbonate
Bulb Shape
PLS-Horizontal
Installation
Base Type
Gx23
Electrical
Power Factor
>0.9
Input Voltage
120-277V
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Compliance
Enclosed Fixtures
Suitable for use in enclosed fixtures
UL Listed
Suitable for damp locations
UL Classified
Yes
Certification Model Number
T10369(PLS-5.2-H-850-HYB)
