LFLED4NLVA

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

LFLED4NLVA

Works with existing 12V AC landscape lighting systems

Replaces 35W MR16 halogen

Reduces energy consumption by 85%

Optional spot and narrow spot reflector kits available

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	4W
Color Temp	4000K (Neutral)
Lumens	433 lm
Efficacy	92.1 lm/W
Color Accuracy	82 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	4.7W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 1.6 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations. Suitable for ground mounting.

Optical

NEMA Type

NEMA Beam Spread 4H x 4V

Spot Lens

Optional spot lens enables a tool-less conversion to a NEMA Type 3H x 3V. Great for accent lighting or grazing buildings for an artistic touch. Spot reflector kit available here.

Narrow Spot Lens

Optional narrow spot lens enables a tool-less conversion to a NEMA Type 3H x 2V. Great for accent lighting or grazing buildings for an artistic touch. Narrow spot reflector kit available here.

Construction

Lens

Microprismatic diffuser produces a smooth distribution and low glare

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 104°F (40°C)

Thermal Management

Optimized using computational fluid dynamics so ftware to ensure long LED and driver lifespan

Housing

Precision die-cast aluminum housing, lens frame and mounting arm

Gaskets

High-temperature silicone

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

LED Characteristics

LED

Multi-chip, high-output, long-life LED

Color Consistency

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.

Electrical

Driver

Class 2, 50/60 Hz, 12VAC Max, 0.5A

Voltage

12V AC

Other

Wiring

30" SPT1 zip cord included. Transformers provided by others.

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Patents

The design of the LFLED is protected by Taiwan Patent 01510966 and pending patents in US, Canada, China, and Mexico
