• Advanced daylight sensing
  • Utility-grade energy metering
  • Remote control and setup from Lightcloud Web App
  • Communicates over secure wireless mesh network - no internet required
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 0.4 lbs

Technical Specifications
Product Details
Application
Roadway fixtures
Mounting Type
ANSI C136.10/C136.41 Receptacle
Compliance
IP Rating
Ingress protection rating of IP65 for dust and water
Construction
Operating Temperature Range
-40°C - 70°C
Electrical
Input
120-277VAC, 50/60Hz
Load Switching Capacity
5A @ 120VAC, Electronic Ballast
5A @ 277VAC, Electronic Ballast
Dimming Circuit: 50mA @10VDC
Connection Type
ANSI C136.10/C136.41 Receptacle
Wireless Range
Line of Sight
1,000 ft
Obstructions
100 ft
Other
Warranty
10-year full hardware warranty with 100% repair/replacement coverage for all properly installed devices. See Lightcloud Warranty Terms.
