LCBA19-9-E26-9RGB-SS
LCBA19-9-E26-9RGB-SS
- Replacement for legacy incandescent and halogen lamps
- Direct Connect to the Lightcloud Blue mobile app via Bluetooth, no Gateway or Hub required
- Use mobile device to configure features for On/Off Control, Dim Level, Color Temperature, Schedules, Scenes, SmartShift and more
- Choose between 16+ million colors to fit any mood
- Tunable White 2200-6500K with smooth transition between color temperatures
Performance
| Watts | 8W |
| Color Temp | Tunable White 2200K-6500K (16+ million colors) |
| Lumens | 800 lm |
| Efficacy | 100 |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 25,000 Hours |
| Type | Constant Current |
| 120V | .075A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 8W |
Dimensions
Weight: 0.1 lbs
Technical Specifications
Lightcloud
Lightcloud Blue Installed
Lightcloud Blue, RAB's wireless lighting control system, eliminates the need for a hub or controller. The app shows the fixtures nearest you first, so an area is set up in minutes, even without internet on site. Lights and schedules keep working if the Wi-Fi goes down, and a Nano adds control from anywhere.
DLC system: N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
Learn more at rablighting.com/lcb.
DLC system: N1XMLOEATBA (Interior); NHCZ2BIA17L (Exterior)
Learn more at rablighting.com/lcb.
Gateway Required
No
Communication Protocol
Bluetooth
Light Shows
No, this product is not compatible with dynamic color changing Light Shows. Contact RAB for more information.
Third-party Integration
Yes, with additional devices, sold separately. Small projects use Nano to link with Amazon Alexa or Google Home for voice control or remote access using those apps. Larger projects require one XDIM Bridge per Area plus a Gateway for full remote access via Lightcloud web portal or mobile app.
Range
Indoor: Up to 60 feet between standard building materials. Building materials such as brick, concrete, and steel construction may require additional Lightcloud Blue devices to extend around an obstruction; Up to 200 feet clear line of sight.
Spacing Criteria
Lightcloud Blue devices should be placed within the specified range to communicate within the network. Building materials such as brick, concrete, and steel construction or heavy vegetation, bushes or trees may require additional Lightcloud Blue devices to extend around an obstruction.
SmartShift
SmartShift
SmartShift is the most advanced - yet easiest to use - circadian lighting system, which syncs white color tuning with the local sunrise and sunset.
Requires the NANO/LCB (sold separately)
Requires the NANO/LCB (sold separately)
Performance
Product Type
RGBW Smart Lamp
Description
Color-changing smart lamps with Lightcloud Blue. Customizable scenes and schedules, and SmartShift technology.
Wattage Equivalency
60W Incandescent
Input Wattage
8W
Lumens (Nominal)
800lm
Efficacy
100lm/W
L70 Lifespan
25,000-Hour LED lifespan based on IES LM-70 results
Electrical
Driver
Constant Current 120V 60 Hz; 120V: 75 mA
Power Factor
0.9
Dimmable
Yes via the Lightcloud Blue mobile app and devices.
This product will not operate properly when connected to a standard (incandescent) dimmer or dimming control.
This product will not operate properly when connected to a standard (incandescent) dimmer or dimming control.
Input Voltage
120V
Operating Temperature
-4°F to 113°F(-20 to 45°C)
Flicker
<30%
LED Characteristics
Beam Angle
220°
Color Temperature
Default: 4000K
Adjustable using the Lightcloud Blue mobile app
Tunable White 2200 - 6500K
16+ million colors
Adjustable using the Lightcloud Blue mobile app
Tunable White 2200 - 6500K
16+ million colors
Color Tuning
Yes, 16+ million colors using Lightcloud Blue
Color Accuracy (CRI)
90 CRI
Natural Spectrum
No
R9 Value
High color performance with R9 greater than 0
Color Consistency
<4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Installation
Mounting
Simple to screw in the RGBW tunable lamp into a compatible socket. The circuit should be wired to constant power, bypass any existing wall switch/dimmer (suggest replacing with a Lightcloud Blue dimmer or remote, contact RAB for more information.)
Base Type
E26 Edison
Construction
Shape
A19
Finish
White
Enclosure Material
Plastic
Lens Finish
Frosted
Compliance
Listings
UL Listed
Environment
Suitable for use indoors and outdoors in dry, damp, or wet environments.
Fixture Rating
Suitable for use in enclosed fixtures
Energy Star Approved
No
Certification Model Number
LCBA19-9-E26-9RGB-SS
California Title 20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
No
California Energy Commission (CEC) Status
Lawful for Sales in California
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
Other
Compatible Products
Combine with other Lightcloud Blue accessories to enhance system features and automations. Learn more here.
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
