L2XB
Performance
| Watts | 20W |
| Color Temp | 3000K-5000K |
| Lumens | 2,000/2,072/2,094 lm |
| Efficacy | 102/105.2/105.8 lm/W |
| Color Accuracy | 81/84/84 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 0.20A |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 19.6/19.7/19.8W |
Dimensions
Weight: 1.4 lbs
Technical Specifications
Field Adjustability
Color Tunable
3 discrete color temperatures
Compliance
UL Listed
Suitable for wet locations
IP Rating
Ingress protection rating of IP65 for dust and water
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
LED Characteristics
LEDs
Long-life, high-efficacy, discrete, surface-mount LEDs
Color Consistency
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.
Electrical
Driver
20W: Constant Current, Class 1, 120V, 60 Hz,120V: 0.20A
THD
13.37% at 120V
Power Factor
97.9% at 120V
Dim to Off
No
Aux Power Supply
No
Photocell
Integrated photocell included with on/off switch (factory default: off)
Sensor Settings
Surge Protection
1 kV
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Construction
Cold Weather Starting
The minimum starting temperature is -4°F (-20°C)
Maximum Ambient Temperature
Suitable for use in up to 122°F (50°C)
Housing
Polycarbonate
Reflector
Polycarbonate
Effective Projected Area (EPA)
2000 square foot
Lens
Polycarbonate lens
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Wall mount
Other
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
