HIDFA-120S-EX39-8CCT-BYP/5SP

Spec Sheet Sensor Compatibility List Instructions Family Spec Sheet Spec Sheet

Replaces traditional metal halide or high pressure sodium HID lamp

Adjustable wattage and CCT allows for in-field customization

Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast

Rated for use in enclosed fixtures in dry or damp locations

View Technical Specs

View Price & Availability

Performance

Watts	120/100/80W
Color Temp	3000/4000/5000K
Lumens	10,800-17,400 lm
Efficacy	135-145 lm/W
Color Accuracy	80 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	1.03A
208V	0.61A
240V	0.54A
277V	0.43A
Input Watts	120/100/80W

Dimensions

Technical Specifications

Performance

Description

Field adjustable lumen output and CCT provide installation flexibility when replacing traditional HID. Integrated AUX port to add lamp-level sensor control.

Wattage Equivalency

320W/400W/600W Metal Halide

Input Wattage

80W/100W/120W

Lumens

80W:
3000K @ 10,800lm; 4000K @ 11,600lm; 5000K @ 11,200lm
100W:
3000K @ 13,500lm; 4000K @ 14,500lm; 5000K @ 14,000lm
120W:
3000K @ 16,200lm; 4000K @ 17,400lm; 5000K @ 16,800lm

Efficacy

80W/100W/120W:
3000K @ 135lm/W; 4000K @ 145lm/W; 5000K @ 140lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

THD

≤20%

Power Factor

≥0.9

Dimmable

Yes, via the Lightcloud Blue mobile app and devices.
This lamp will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

100-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

1,031mA

Input Current @ 208V (mA)

613mA

Input Current @ 240V (mA)

543mA

Input Current @ 277V (mA)

433mA

Operating Temperature

-22°F to 140°F (-30°C to 60°C)

Flicker

<30%

Surge Protection

4kV

LED Characteristics

Color Temperature

Field adjustable via dip switch 3000/4000/5000K

Color Accuracy (CRI)

≥80 CRI

R9 Value

High color performance with R9 no less than 0

Color Consistency

<6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Installation

Installation Method

UL Type B, Ballast Bypass

Installation Orientation

Vertical

Base Type

EX39

Construction

Finish

Clear

Bulb Shape

Post top (sensor)

Endcap Material

Metal

Enclosure Material

Polycarbonate

Compliance

Listings

UL Listed, UL Classified

Environment

Suitable for use in dry and damp environments

Fixture Rating

Suitable for use in enclosed fixtures

IP Rating

IP64

Certification Model Number

H20042(HIDFA-120S-EX39-8CCT-BYP/5SP)

California Energy Commission (CEC) Status

Lawful for Sales in California

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15B of the FCC Rules

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PZW8AHTW

Other

Compatible Products

Add the Lightcloud Blue 5-Pin Plug-in Controller with optional sensor to connect to the Lightcloud Blue Bluetooth Mesh Wireless Network Lighting Control System. Learn more about Lightcloud Blue.

Accessories

CONTROL/W/AUX/5SP/LCB
Lightcloud Blue 5-Pin Plug-in Controller
CONTROL/W/AUX/5SP/LCBS
Lightcloud Blue 5-Pin Plug-in Controller with PIR Sensor
CONTROL/W/AUX/5SP/LCBS/MVS
Lightcloud Blue 5-Pin Plug-in Controller with MVS Sensor

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
