HAYBAY130N/D10
HAYBAY130N/D10
- Simple. Affordable, Modular design.
- Open "airflow" design reduces operating temperatures and increases lifespan
- Assortment of reflectors tailor the Haybay to specific applications
- Available with a Lightcloud Controller, Lightcloud Sensor and other compatible RAB sensors
Performance
| Watts | 130W |
| Color Temp | 4000K (Neutral) |
| Lumens | 20,580 lm |
| Efficacy | 153.9 lm/W |
| Color Accuracy | 72 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | 1.09A |
| 208V | 0.63A |
| 240V | 0.55A |
| 277V | 0.47A |
| Input Watts | 133.7W |
Dimensions
Weight: 14.7 lbs
Technical Specifications
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Construction
Vibration Rating
Industry-leading 5G vibration rating per ANSI C136.31
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use 12 hours a day, 5 days a week in up to 50°C and for 24/7 use in up to 40°C
Housing
Precision die-cast aluminum with sheet metal driver bracket/mounting
Finish
Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
LED Characteristics
LEDs
Long-life, high-efficiency, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 250W Pulse Start Metal Halide
Electrical
Drivers
Class 1, programmable, constant current, 50/60 Hz., 120-277V, 120V: 1.09A, 208V: 0.63A, 240V: 0.55A, 277V: 0.47A
Surge Protection
4 kV
Installation
Mounting
Heavy-duty 3/4" NPS hook and 6 ft cord; is also 3/4" pendant mount capable
(pendant by others).
Other
Reflector Options
Clear prismatic acrylic reflectors available in 11" or 8.5" height; frosted prismatic acrylic reflectors available in 11" or 8.5" height; white aluminum
reflector available in 5" height. Click here to see all reflectors.
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
