• 100,000-Hour LED lifespan
  • IP65 rating protects against dust and water
  • DLC Premium listed
  • IK10 Rating
  • Industry-leading 3G vibration rating per ANSI C136.31
  • 10-Year, Limited warranty
View Technical Specs
Performance
Watts 520W
Color Temp 5000K
Lumens 67,096 lm
Efficacy 132.7
Color Accuracy 83 CRI
L70 Lifespan 100,000 Hours
Type Constant Current
120V
208V 2.52A
240V 2.19A
277V 1.89A
Input Watts 505.6W
Dimensions
Link to Dimension Drawing

Weight: 37.7 lbs

Technical Specifications
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP65 for dust and water
DLC Listed
This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.
Electrical
Driver
Constant Current, Class 1, 208-480V, 50/60 Hz, 208V: 2.50A 240V: 2.17A, 277V: 1.85A, 480V: 1.09A
Dimming Driver
Driver includes wiring for 0-10V dimming systems. Dim as low as 10%.
Surge Protection
20 kV
Aux Power Supply
Yes
Dim to Off
Yes
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Construction
IK Rating
IK10 Protected against 20 joules impact. Equivalent to impact of 11 lbs (5kg) mass dropped from 15.8" (400mm) above impacted surface.
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Maximum Ambient Temperature
Suitable for use in up to 104°F (40°C)
Housing
Precision die-cast aluminum
Lens
Polycarbonate lens
Vibration Rating
3G vibration rating per ANSI C136.31
Tilt Increment
Continuous tilting with 5° increments
Reflector
Polyethylene Terephthalate (PET)
Effective Projected Area (EPA)
EPA = 3.2
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Optical
NEMA Type
NEMA Beam Spread 3H x 4V
Installation
Mounting
Trunnion mount with stainless steel hardware
Other
10-Year Limited Warranty
The RAB 10-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
