EZPANFA1X4/D10
EZPANFA1X4/D10
30W 3500/4000/5000K
- Field-adjustable light output (3 discrete steps)
- White tunable (3 discrete color temperatures)
- Can be changed before, during or after installation
- 75,000-Hour LED lifespan
Performance
| Watts | 30W |
| Color Temp | 3500/4000/5000K |
| Lumens | 3,007-4,612 lm |
| Efficacy | 115.3-125.7 lm/W |
| Color Accuracy | 82-83 CRI |
| L70 Lifespan | 75,000 Hours |
| Type | Constant Current |
| 120V | 0.25A |
| 208V | 0.15A |
| 240V | 0.13A |
| 277V | 0.12A |
| Input Watts | 24.6-38.34W |
Dimensions
Weight: 11.6 lbs
Technical Specifications
Field Adjustability
Field Adjustable
Field Adjustable Light Output:
1' x 4': 40W/30W/25W(factory default 30W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)
1' x 4': 40W/30W/25W(factory default 30W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)
Compliance
UL Listed
Suitable for damp locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
CCEA Compliant
Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago
Trade Agreements Act Compliant
This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PEQ7BMXZ
DLC Product Code: PEQ7BMXZ
Performance
Lifespan
75,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
LED Characteristics
LEDs
Edge-lit design with long-life, high-efficacy LEDs
Construction
Operating Temperature
-30°C (-22°F) to 40°C (104°F)
Lens
Frosted polystyrene
Housing
Lightweight aluminum housing
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Recessed ceiling
Other
Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.12A
THD
6.37% at 120V, 6.63% at 277V
Power Factor
99.6% at 120V, 93.8% at 277V
