EZPAN2X4-50/D10

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

EZPAN2X4-50/D10

Perfect for shallow plenums

Even and diffuse ambient illumination, ideal for spaces where glare-free lighting is required

0-10V dimmable driver, standard

View Technical Specs

View Price & Availability

Performance

Watts	50W
Color Temp	5000K (Cool)
Lumens	5,678 lm
Efficacy	115.2
Color Accuracy	85 CRI
L70 Lifespan	60,000 Hours

Type	Constant Current
120V	0.42A
208V	0.25A
240V	0.21A
277V	0.18A
Input Watts	49.3W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 15.8 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

CCEA Compliant

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PUC5386Y

Performance

Lifespan

60,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Wattage Equivalency

Equivalent to (4)F32T8 or (4)F28T5

Electrical

Driver

Constant Current, Class 2, 50/60 Hz, 120-277V, 120V: 0.42A, 208V: 0.25A, 240V: 0.21A, 277V: 0.18A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

8.87% at 120V, 5.3% at 277V

Power Factor

99.2% at 120V, 96.7% at 277V

Construction

IC Rated

Suitable for insulated ceilings

Maximum Ambient Temperature

Suitable for use in up to -30°C (-22°F) to 50°C(122°F)

Lens

Frosted polystyrene

Housing

Lightweight aluminum housing, steel pan and junction box

Installation

Standard integral T-bar clips secure the fixture to T-bars and prevent T-system separation

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Installation

Mounting

Recessed ceiling

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
