EXITOUT-GC
EXITOUT-GC
- Wet-location LED exit sign for outdoor and wet environments, IP65
- White thermoplastic housing, 5VA flame rating
- Red or green letter models, 6" high with 3/4" stroke
- Universal J-box mounting pattern
- 90-minute battery backup; Meets UL924, NFPA 101 Life Safety Code, NEC and OSHA illumination standards
Dimensions
Weight: 3.6 lbs
Technical Specifications
Performance
Product Type
Outdoor Exit Sign
Description
Outdoor exit sign with a single face and green letters. Wet and cold weather rated.
Input Wattage
3.3W
Electrical
Power Factor
≥0.9
Input Voltage
Dual 120/277 Voltage
Operating Frequency (Hz)
60Hz
Input Current @ 120V (mA)
30mA
Input Current @ 277V (mA)
14mA
Dual Voltage Circuit Operation
No
Operating Temperature
-4°F to 122°F (-20°C to 50°C)
Battery Type
Nickel Cadmium
Storage Temperature
68°F to 86°F (20°C to 30°C)
Storage Shelf Life
3 years before the initial charge. 5 years after initial charge.
Self Diagnostics
No, manual test only
Remote Test Switch
No
Emergency Characteristics
Emergency Illumination
90 minutes
Battery Backup
Yes
Battery Voltage
4.8V
Recharge Time Required
24-hours
Battery Operating Temperature
-20°F to 50°F (-4°C to 122°C)
Installation
Mounting Method
Back/Top/End
Mounting Type
Wall/Ceiling Mount
Cold Weather Rated
Yes
Construction
Shape
Rectangle
Housing Material
Thermoplastic
Panel Material
Thermoplastic
Panel Color
White
Letter Color
Green
Housing Color
White
Number of Faces
Single Face
Arrow Direction
No Arrow
Sign Format
Stencil
Remote Capacity
No
Compliance
Listings
UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards
Environment
Suitable for indoor or outdoor use in dry, damp, and wet environments
IP Rating
Outdoor
Certification Model Number
WLEZXTEU1GWEM-CW
T20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
Not applicable
California Energy Commission (CEC) Status
Lawful for Sales in California
FCC
Complies with Part 15 of the FCC Rules
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Battery is prorated.
Battery is prorated.
