EXITEDGE-WPDACH/E
Dimensions
Weight: 0.8 lbs
Technical Specifications
Performance
Product Type
Emergency remote head
Input Wattage
2.4W
Electrical
Input Voltage
3.6-15V
Input Current @ 120V (mA)
600mA
Operating Temperature
32°F to 104°F (0°C to 40°C)
Emergency Backup
Self Diagnostics
No
Remote Test Switch
No
Installation
Mounting Method
Back
Mounting Type
Wall
Construction
Cold Weather Rated
No
Housing Material
Thermoplastic
Housing Color
White
Housing Flamability
5VA
No. of Heads
2-Lamp Heads
Head Shape
Square
Remote Head Power (W)
2.4W
Remote Head Lumens (lm)
180lm
Remote Heads Replaceable
No
Compliance
Listings
UL Listed
Environment
Suitable for use indoors in dry and damp environments.
IP Rating
IP20
T20 Compliant
No
California Title 24 JA8 Compliant
No
California Energy Commission (CEC) Status
Lawful for Sales in California
City Compliance
None
FCC
Complies with Part 15 of the FCC Rules
Other
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
