EXITEDGE-WPDACH

Spec Sheet Instructions Spec Sheet

EXITEDGE-WPDACH

Chicago-approved double-face edge-lit exit sign

White acrylic panel with red letters

Aluminum housing in white or brushed aluminum finish

Surface or recessed mounting models

AC-only and 90-minute battery backup models available

View Technical Specs

View Price & Availability

Dimensions

Weight: 1.8 lbs

Technical Specifications

Performance

Product Type

Exit Combo

Description

Ultra-economy exit sign combo with 90-minute emergency battery backup unit.

Input Power (W)

Lumens

160lm

Electrical

Power Factor

0.4

Input Voltage

120-277V

Operating Frequency

50/60Hz

Input Current @ 120V (mA)

45mA

Input Current @ 277V (mA)

20mA

Maximum Output Wattage

4.2W

Dual Voltage Circuit Operation

Operating Temperature

32°F to 104°F (0°C to 40°C)

Emergency Illumination

90 minutes

Battery Type

Nickel-Metal Hydride

Battery Voltage

3.6V

Recharge Time Required

24-hours

Battery Operating Temperature

0°F to 50°F (32°C to 122°C)

Storage Temperature

32°F to 104°F (0°C to 40°C)

Storage Shelf Life

3 years before the initial charge. 5 years after initial charge.

Self Diagnostics

No, manual test only

Remote Test Switch

Emergency Backup

Battery Backup

Yes

Installation

Mounting Method

Back/Top/Side

Mounting Type

Wall/Ceiling Mount

Maximum Mounting Height (ft.)

20 ft

Spacing Criteria for Emergency Egress

14 ft on center assuming 7.5 ft mounting height with egress path 3 ft out

Cold Weather Rated

Construction

Shape

Rectangle

Housing Material

Thermoplastic

Housing Color

White

Panel Material

Thermoplastic

Panel Color

White

Letter Color

Red/Green

Number of Faces

Universal Single/Double Face

Arrow Direction

Left/Right Arrow

Sign Format

Stencil

Remote Capacity

Yes

No. of Heads

2-Lamp Heads

Head Shape

Round

Remote Head Power (W)

1.8W

Remote Head Lumens (lm)

160lm

Remote Heads Replaceable

Remote Power (W) Capacity

Compliance

Listings

UL924 Listed

Environment

Suitable for use in dry and damp environments

IP Rating

IP20

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
