• NYC-approved universal-face steel exit sign (single or double face)
  • White steel housing with red letters
  • AC-only and 90-minute battery backup models available
  • Wall or ceiling mount: back, top or end
  • Meets UL924, NFPA 101 Life Safety Code, NEC and OSHA illumination standards
View Technical Specs
Dimensions
Link to Dimension Drawing

Weight: 5.4 lbs

Technical Specifications
Performance
Product Type
New York City-Compliant Exit Sign
Description
New York City-approved exit sign with a universal face and red letters.
Input Wattage
5W @120V and 277V
Electrical
Power Factor
≥0.9
Input Voltage
Dual 120/277 Voltage
Operating Frequency (Hz)
60Hz
Input Current @ 120V (mA)
41mA
Input Current @ 277V (mA)
18mA
Dual Voltage Circuit Operation
No
Operating Temperature
68°F to 86°F (20°C to 30°C)
Storage Temperature
68°F to 86°F (20°C to 30°C)
Self Diagnostics
No, manual test only
Remote Test Switch
No
Emergency Characteristics
Battery Backup
No, AC only
Battery Operating Temperature
68°F to 86°F (20°C to 30°C)
Installation
Mounting Method
Back/Top/End
Mounting Type
Wall/Ceiling Mount
Cold Weather Rated
No
Construction
Shape
Rectangle
Housing Material
Steel Sheet
Panel Material
Steel Sheet
Panel Color
White
Letter Color
Red
Housing Color
White
Number of Faces
Universal Single/Double Face
Arrow Direction
No Arrow
Sign Format
Stencil
Remote Capacity
No
Compliance
Listings
UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards
Environment
Suitable for indoor use in dry and damp environments
IP Rating
Indoor
Certification Model Number
NYXTEU3RW
T20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
Not applicable
California Energy Commission (CEC) Status
Lawful for Sales in California
City Compliance
New York City Approved
FCC
Complies with Part 15 of the FCC Rules
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
