EXIT-DACH/E

Spec Sheet EM Remote Head Compatibility List Instructions Spec Sheet

EXIT-DACH/E

Double-face panel with red letters

Steel housing

Approved for use in the city of Chicago

Compliant with California Title 20

View Technical Specs

View Price & Availability

Dimensions

Weight: 4.9 lbs

Technical Specifications

Performance

Product Type

Chicago-Approved Steel Exit/Stair Sign

Description

Chicago-approved exit sign with a universal face, red letters, and 90 minutes of emergency battery backup.

Input Wattage

5W @120V and 277V

Electrical

Power Factor

≥0.4

Input Voltage

Dual 120/277 Voltage

Operating Frequency (Hz)

60Hz

Input Current @ 120V (mA)

10mA

Input Current @ 277V (mA)

50mA

Dual Voltage Circuit Operation

Operating Temperature

32°F to 122°F (0°C to 50°C)

Emergency Illumination

120 minutes

Battery Backup

Yes

Battery Type

Nickel Cadmium

Battery Voltage

4.8V

Recharge Time Required

24-hours

Battery Operating Temperature

32°C to 122°C (0°F to 50°F)

Storage Temperature

68°F to 86°F (20°C to 30°C)

Storage Shelf Life

3 years before the initial charge. 5 years after initial charge.

Self Diagnostics

No, manual test only

Remote Test Switch

Installation

Mounting Method

Top/End

Mounting Type

Wall/Ceiling Mount

Cold Weather Rated

Construction

Shape

Rectangle

Housing Material

Steel Sheet

Panel Material

Glass

Panel Color

White

Letter Color

Red

Housing Color

White

Number of Faces

Universal Single/Double Face

Arrow Direction

Double Arrow

Sign Format

Panel

Remote Capacity

Compliance

Listings

UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards

Environment

Suitable for indoor use in dry and damp environments

IP Rating

Indoor

Certification Model Number

CAXTEU2RWEM-DA

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

Not applicable

California Energy Commission (CEC) Status

Lawful for Sales in California

City Compliance

Chicago Approved

FCC

Complies with Part 15 of the FCC Rules

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Battery is prorated.
