EVC48
- Residential and Commercial EV Charging
- 48A-11.5kW Single Phase
- IP56/NEMA Type4/IK08 Protection
- Support for RFID Card and QR Code for User Authentication and Management
- OCPP or Local Load Management
Dimensions
Weight: 16.1 lbs
Technical Specifications
Performance
Description
48A / 11.5 kw Residential/Commercial Charger: 4G networked, OCPP 1.6J protocol, 16.4' Cord, 5-inch LCD display, configurable power, and ISO 15118 protocol.
Protocol
OCPP 1.6 JSON (Upgradeable to 2.0)
Output Power
11.5kW
Power Configurable
6A, 8A, 10A, 13A, 16A, 20A, 25A, 30A, 32A, 40A, 48A. Default setting: 48A
Network Connectivity
Ethernet + Wi-Fi (IEEE 802.11 b/g/n) + 4G
RFID + QR Code Capability
Included
Load Management
Online or Local
OTA Capability
Included
Cable Management
Optional with accessories sold seperately
Authentication Method
Smart Phone App, ISO 15118, RFID (ISO/IEC 14443A/B, ISO/IEC 15693, FeliCa™, MIFARE)
Electrical
Charging Interface
SAEJ1772 Type 1
Input Current
48A
Operating Frequency
50/60Hz
Input Voltage
200-240V, Single Phase
AC Input Connection
L1/L2/GND
Output Current
48A (max) (with AC breaker capacity selection)
Power Quality
SAE J2894 Compliant
Operating Temperature
-22°F to 122°F (30°C to 50°C)
Humidity
Max 85%
Input Side Protection
UVP, OVP, Surge Protection, Ground Fault
Output Side Protection
OCP, Control Pilot Fault, Residual Current Protection
Internal Protection
OTP, Relay Welding Detection, CCID Self-Test, MCU Function Fault Detection
Rating of Branch Circuit Breaker
60A
Input Wire Size
6 AWG
Metering Accuracy
Meter IC (1% Accuracy)
Construction
Display Screen
5-inch LCD display, LED Indicator
Number of Ports
Single
Charging Cable
16.4 ft
Finish
Black
Tamper Resistant
IK08 rated to protect the unit against external mechanical impacts (not rated for the LCD display screen or RFID)
Installation
Mounting
Wall, Single or Double Pedestal
Hardwired
Yes
Compliance
Listings
UL Listed, UL 2594; UL2231-1/-2
Shock Protection
CCID20. A charging circuit interrupting device (CCID) automatically interrupts the circuit when the current reaches or exceeds the threshold current of 20mA.
OpenADR
No
IP Rating
Ingress protection rating of IP56 for dust and water
NEMA Rating
Type 4, weatherproof protection
California Type Evaluation Program (CTEP)
This product meets the requirements of the California Type Evaluation Program (CTEP).
Energy Star Approved
Yes
Energy Star ID
2732754
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
\
Other
Compatible Accessories
EVPS Single Pedestal Base
EVMS Single Cable Management Add-On (Top) 16.4ft
EVPD Dual Pedestal Base
EVMD Dual Cable Management Add-On (Top) 16.4ft
EVCARD-CL - RFID Card
EVMS Single Cable Management Add-On (Top) 16.4ft
EVPD Dual Pedestal Base
EVMD Dual Cable Management Add-On (Top) 16.4ft
EVCARD-CL - RFID Card
Warranty
RAB warrants that our products will be free from defects in materials for a period of three (3) years from the date of delivery to the end user. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
