Dimensions
Weight: 14.3 lbs
Technical Specifications
Performance
Product Type
EVC Level 2, 40A Series
Description
40A / 9.6 kw Residential Charger / 25' Cord / No display, LED indicator light
Output Power
9.6 kW
Power Configuration Settings
Max 40A
Electrical
Charging Interface
SAEJ1772 Type 1
Input Current
40A
Operating Frequency
50/60Hz
Input Voltage
200-240V, Single Phase
AC Input Connection
NEMA 14-50 plug
Output Current
40A (max)
Operating Temperature
-22°F to 131°F (-30°C to + 55°C)
Humidity
Max 90%
Input Side Protection
Leakage protection, Over-voltage protection, Over current protection, Under-voltage protection, Short circuit protection, Over temperature protection
Output Side Protection
Leakage protection, Over-voltage protection, Over current protection, Under-voltage protection, Automatic full
charge protection, Control pilot fault protection, Short circuit protection, Over temperature protection
Internal Protection
OTP, Relay Welding Detection, CCID Self-Test, MCU Function Fault Detection
Rating of Branch Circuit Breaker
50A
Input Wire Size
8 AWG
Metering Accuracy
Meter IC (1% Accuracy)
Construction
Display Screen
No Display
Number of Ports
Single
Charging Cable
25 ft
Finish
Silver
Tamper Resistant
IK08 rated to protect the unit against external impacts
Installation
Mounting
Wall
Hardwired
No
Compliance
Listings
ETL Listed
Shock Protection
CCID20. A charging circuit interrupting device (CCID) automatically interrupts the circuit when the current reaches or exceeds the threshold current of 20mA.
OpenADR
No
IP Rating
Ingress protection rating of IP65 for dust and water
NEMA Rating
Type 4, weatherproof protection
California Type Evaluation Program (CTEP)
No
Energy Star Approved
Yes
Energy Star ID
3417980
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15 of the FCC Rules
Other
Compatible Accessories
EVPS Single Pedestal Base
EVPD Dual Pedestal Base
EVPD Dual Pedestal Base
3-Year Limited Warranty
Electric Vehicle Charger products will be free from defects in materials and workmanship for a period of (3) years from the date of original sale to RAB's distributor. The product shall be considered defective only if it cannot be brought back to service by assistance from RAB technical product support representative. If you have a technical issue or question regarding warranty, call our technical support team at RAB Help line. Exceptions apply as stated on product specification sheets incorporated herein by reference. Defects in material or workmanship do not include improper installation or operation, alterations, power surges or overheating due to external conditions. Defects caused by acts of vandalism and incidents beyond control of manufacturer resulting in inoperability of the electric vehicle charger are not covered by the material or workmanship warranty.
Buy American Act Compliance
No
