EMOUT-S/PC

Spec Sheet EM Remote Head Compatibility List Instructions Spec Sheet

EMOUT-S/PC

Durable aluminum design

Remote head, see Remote Head Compatibility List

Integrated photocell

Self-diagnostic

Outdoor rated for dry, damp, and wet environments

View Technical Specs

View Price & Availability

Dimensions

Weight: 3.8 lbs

Technical Specifications

Performance

Product Type

Emergency Unit

Description

Decorative Outdoor Die-Cast AC/Emergency Unit

Input Power

2.5W

Lumens

1,286lm AC; 350lm DC

Electrical

Power Factor

0.3

Input Voltage

Dual 120/277 Voltage

Frequencies

50/60 Hz

Input Current @ 120V (mA)

21mA

Input Current @ 277V (mA)

9mA

Dual Voltage Circuit Operation

Operating Temperature

32°F to 122°F (0°C to 50°C)

Emergency Illumination

90 minutes

Battery Type

Nickel Cadmium

Battery Voltage

4.8V

Recharge Time Required

24-hours

Battery Operating Temperature

32°C to 122°C (0°F to 50°F)

Storage Temperature

68°F to 86°F (20°C to 30°C)

Storage Shelf Life

3 years before the initial charge. 5 years after initial charge.

Self Diagnostics

Yes

Remote Test Switch

Installation

Mounting Method

Back

Mounting Type

Wall Mount

Maximum Mounting Height (ft.)

10 ft

Emergency Egress Coverage(ft) Mounting at height of 7.5ft

29 ft x 3 ft mounted @ 7.5 ft

Spacing Criteria for Emergency Egress

45 ft on center assuming 7.5 ft mounting height with egress path 3 ft out

Cold Weather Rated

Construction

Shape

Rectangle

Housing Material

Die Cast Aluminum

Housing Color

Bronze

Remote Capacity

Compliance

Listings

UL924 Listed

Environment

Suitable for indoor or outdoor use in dry, damp, and wet environments

IP Rating

Indoor/Outdoor

Certification Model Number

DBEL-ACEM-HL-BR-SDT-PC

T20 Compliant

Not Title 20 Compliant

California Title 24 JA8 Compliant

Not applicable

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Battery is prorated.
