ECOMBO-RS

Universal Mounting and Double-face with interchangable red/green color letters

Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white housing finish

90 minutes of battery backup & Compatible with remote heads

Remote output power 2W at 3.6VDC. Supports up to two (2) single or one (1) double 3.6VDC remote heads

Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,Local and State Codes. Compliant with California Title 20

View Technical Specs

View Price & Availability

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 3.2 lbs

Technical Specifications

Performance

Product Type

Color Switching, Thermoplastic Exit Combo

Product Series

ECOMOBO Exit Sign Combo

Description

Thermoplastic exit combo that provides red/green switching capability in the field. Available in a white finish with square lamp heads.

Input Power (W)

2.8W

Lumens (lm)

180lm

Construction

Housing Material

Injection-molded thermoplastic ABS housing, UL 94V-0 flame rating

Housing Finish

White Finish

Lettering

Features 6" height letters with 3/4" stroke in both red and green colors.

Face Configuration

Supplied with two faces for single or double face installation

Arrow Configuration

Field-installable, removable chevron directional indicators for all configurations

Illumination Source

2 Lamp Heads

Optical System

Precision engineered Prismatic Lens

Head Orientation

Adjustable heads for aiming light where required

Remote Capable

Yes - Remote version supports up to two (2) 3.6VDC Remote Heads

LED Characteristics

Color Temperature

6500K

Electrical

Power Factor

0.4

Input Voltage (V)

Universal 120-277 Voltage

Operating Frequency

50/60Hz

Input Current @ 120V (A)

0.045A

Emergency Characteristics

Battery Backup

Yes

Emergency Illumination

90 minutes

Battery

Built -in 3.6V 2400mAh Ni-MH battery for minimum 90 minutes emergency operation

Battery Voltage

Recharge Time

Maximum 24 hours for full recharge time

Battery Operating Temperature

32°F to 122°F (0°C to 50°C)

Testing Method

Self Diagnostic feature automatically tests and reports on fixture status

Installation

Mounting

Universal J-Box Mounting Pattern

Application

Wall Mount

Mounting Height

9.3 ft

Compliance

Listings

UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards

Environment

Suitable for use in dry and damp environments. Not suitable for applications with direct sunlight.

IP Rating

IP20

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

Standard Remote Heads
EREMOTE-1
EREMOTE
EREMOTE-1B
EREMOTE-B
Water Proof Remote Heads
EREMOTEOUT-1
EREMOTEOUT
EREMOTEOUT-1B
EREMOTEOUT-B
EREMOTEOUT-1W
EREMOTEOUT-W

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
