ECOMBO-B

Exit sign + emergency light combo; supplied with two faces for single- or double-face installation

Thermoplastic housing in white or black finish (by model), UL 94V-0

Red/green selectable letters, 6" high with 3/4" stroke; adjustable LED heads

90-minute battery backup; self-diagnostic model available

Meets UL924, NFPA 101 Life Safety Code, NEC and OSHA illumination standards; compliant with California Title 20

View Technical Specs

View Price & Availability

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 4.2 lbs

Technical Specifications

Performance

Product Type

Color Switching, Thermoplastic Exit Combo

Product Series

ECOMOBO Exit Sign Combo

Description

Thermoplastic exit combo that provides red/green switching capability in the field. Available in a white finish with square lamp heads.

Input Power (W)

3.5W

Lumens (lm)

180lm

Maximum Output Wattage (W)

2.4W

Construction

Housing Material

Injection-molded thermoplastic ABS housing, UL 94V-0 flame rating

Housing Finish

Black Finish

Lettering

Features 6" height letters with 3/4" stroke in both red and green colors.

Face Configuration

Supplied with two faces for single or double face installation

Arrow Configuration

Field-installable, removable chevron directional indicators for all configurations

Illumination Source

2 Lamp Heads

Optical System

Precision engineered Prismatic Lens

Head Orientation

Adjustable heads for aiming light where required

LED Characteristics

Color Temperature

6500K

Electrical

Input Voltage (V)

Universal 120-277 Voltage

Operating Frequency

50/60Hz

Input Current @ 120V (A)

0.031A

Input Current @ 277V (A)

0.016A

Operating Temperature

32°F to 104°F (0°C to 40°C)

Emergency Characteristics

Battery Backup

Yes

Emergency Illumination

90 minutes

Battery Voltage

3.6V

Recharge Time

Maximum 24 hours for full recharge time

Battery Operating Temperature

32°F to 122°F (0°C to 50°C)

Testing Method

Integrated Test Switch & Charge Indicator

Other

Battery

Built -in 3.6V 1200mAh Ni-MH battery for minimum 90 minutes emergency operation

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Installation

Mounting

Universal J-Box Mounting Pattern

Application

Wall Mount

Mounting Height

9.3 ft

Compliance

Listing

UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards

Environment

Suitable for use in dry and damp environments. Not suitable for applications with direct sunlight.
