A19-8-E26-922/30-WGD
A19-8-E26-922/30-WGD
- Replacement for conventional decorative lamps
- Filament LED construction gives a unique traditional look and feel for decorative and ambient applications
- Rated for use in enclosed and open fixtures in dry and damp locations
- Longer lifespan compared to legacy equivalents minimizes replacement and maintenance costs
- ENERGY STAR Compliant, UL Listed
- Smooth warm to dim transition between 2200K to 3000K color temperatures
- Uniform dimming down to 10% (See Dimmer Compatibility List)
Performance
| Watts | 8W |
| Color Temp | 2200/3000K |
| Lumens | 800 lm |
| Efficacy | 94.1 |
| Color Accuracy | 90 CRI |
| L70 Lifespan | 15,000 Hours |
| Input Voltage | 120V |
| Power Factor | 0.7 |
| Flicker | N/A |
| THDi | 58 |
Dimensions
Weight: 0.1 lbs
Technical Specifications
Performance
Product Type
A-Line
Input Wattage
8.5W
Lumens
800lm
Efficacy
94.1lm/W
L70 Lifespan
15,000-Hour LED lifespan based on IES LM-70 results
Wattage Equivalency
60W Incandescent
Compliance
UL Listed
Suitable for damp locations
Enclosed Fixtures
Suitable for use in enclosed fixtures
LED Characteristics
Color Temperature
2200/3000K
Color Accuracy (CRI)
>90 CRI
Beam Angle
230°
Electrical
THD
58%
Power Factor
0.7
Dimmable
Yes
Operating Temperature
-20°C to 45°C (-4°F to 113°F)
Input Voltage
120V
Operating Frequency
60 Hz
Construction
Shape
A19
Endcap Material
Polycarbonate
Enclosure Material
Plastic
Installation
Base Type
E26 Edison
Other
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
