LOS800W/120
LOS800W/120
- Sensitive 180° view passive infrared motion detector keeps lights on only when rooms are in use
- LED detection indicator
- Tough, vandal resistant lens
- Fits decorator wall plates
- Control panel cover only removable with wall plate to prevent tampering
- Manual off/auto switch
- Vandal proof sensor for schools, gyms and high abuse areas
Dimensions
Weight: 0.3 lbs
Technical Specifications
Compliance
UL Listed
Indoor applications Smart Box & Tuff Dome Wet locations
Other
Compatibility
Compatible with most electronic ballasts. Not compatible with instant start ballasts. Can be wired in parallel.
1-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of one (1) year from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Electrical
Maximum Energy Savings
Light only when you need it. No ON switch so lights are never left on by mistake.
Incandescent & Fluorescent Watts Switched
800W @ 120 volts
Ratings
6.7 amps.
Power Consumption
Negligible
Manual Switch
On - Manual / Off - Auto
Wiring
Hot & common
Optical
Coverage Area
1000sf
Sensor Settings
Time Delay
8 seconds to 15 minutes
Ambient Light Sensing
n/a
Adjustments
Time
Detection
180° view covers 1000 sq. ft.
