HAZSHARK4/E

Class 1, Division 2, Groups A, B, C, D

Class 2, Division 1, Groups E, F, G

Class 2, Division 2, Groups F, G

Class 3

IP66, UL1598, UL8750 and UL 844 ratings

DLC Listed

50,000-Hour LED lifespan

5-Year, no-compromise warranty

View Technical Specs

View Price & Availability

Performance

Watts	50W
Color Temp	5000K
Lumens	7,024 lm
Efficacy	143.3 lm/W
Color Accuracy	84 CRI
L70 Lifespan	50,000 Hours

Type	Constant Current
120V	0.41A
208V	0.24A
240V	0.21A
277V	0.19A
Input Watts	49W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 19.7 lbs

Technical Specifications

Hazardous Location Classifications

Class 1, Division 2 (Groups A, B, C, D)

Class 1 (Hazardous Material in Surrounding Atmosphere):
Flammable vapors or gases may be present

Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions

Groups A, B, C, D (Hazardous Material in Surrounding Atmosphere):
A = Acetylene
B = Hydrogen, butadiene, ethylene oxide, propylene oxide and acrolein
C = Ethylene, cyclopropane and ethyl ether
D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene

Class 2, Division 1 (Groups E, F, G)

Class 2 (Hazardous Material in Surrounding Atmosphere):
Combustible dust may be present

Division 1 (Presence of Hazardous Materials):
Ignitable concentrations of hazard exists under normal operating conditions

Groups E, F, G (Hazardous Material in Surrounding Atmosphere):
E = Combustible metal dusts: aluminum, commercial alloys and magnesium
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood

Class 2, Division 2 (Groups F, G)

Class 2 (Hazardous Material in Surrounding Atmosphere):
Combustible dust may be present

Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions

Groups F, G (Hazardous Material in Surrounding Atmosphere):
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood

Class 3

Class 3 (Hazardous Material in Surrounding Atmosphere):
Easily ignitable flyings or fibers may be present

UL 844

Electric lighting fixtures for use in hazardous (classified) locations

Compliance

UL Listed

Suitable for wet locations

UL Marine Listed

Marine Listed Outside Type (Saltwater)

UL 924

Charge Time: 24 hours
Emergency Run Time: 90 min

IP Rating

Ingress protection rating of IP66 for dust and water

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-1MDUOR (Hazardous Environment Low-Bay)
DLC Product Code: S-3V8FBW (Hazardous Direct Linear Ambient Luminaires)

Electrical

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

1.47% at 120V, 3.24% at 277V

Power Factor

99.6% at 120V, 92.0% at 277V

Surge Protection

4kV

Battery Backup

Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.

Construction

Housing

Stainless steel

Rated Ambient Temperature Range

-10°C (14°F) to 50°C (122°F), T5

Lens

Clear polycarbonate* lens.

*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.

Gaskets

High-temperature silicone

Green Technology

Mercury and UV free. RoHS-compliant components.

Finish

Formulated for high durability and long-lasting color

Installation

Mounting

Two mounting options included: stainless steel, surface mount brackets or aircraft cable for suspended mount.

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs

Color Stability

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Performance

Lifespan

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

Buy American Act Compliance

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.
