EZPANFA2X4/D10/E2

Spec Sheet IES File Instructions Spec Sheet EZ Layout

EZPANFA2X4/D10/E2

40W 3500/4000/5000K

Field-adjustable light output (3 discrete steps)

White tunable (3 discrete color temperatures)

Can be changed before, during or after installation

75,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	40W
Color Temp	3500/4000/5000K
Lumens	3,809-6,104 lm
Efficacy	116.1-132.2 lm/W
Color Accuracy	83-84 CRI
L70 Lifespan	75,000 Hours

Type	Constant Current
120V	0.33A
208V	0.20A
240V	0.17A
277V	0.15A
Input Watts	29.8-49.3W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 13.4 lbs

Technical Specifications

Field Adjustability

Field Adjustable

Field Adjustable Light Output:
2' x 4': 50W/40W/30W (factory default 40W)
Color temperature selectable by 3500K, 4000K and 5000K (factory default 4000K)

Compliance

UL Listed

Suitable for damp locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

CCEA Compliant

Luminaire Requirements used in Environmental Air Space per the electrical code specification of the City of Chicago

Trade Agreements Act Compliant

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PL3725S1

Performance

Lifespan

75,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

LED Characteristics

LEDs

Edge-lit design with long-life, high-efficacy LEDs

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.33A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A

THD

4.09% at 120V, 9.62% at 277V

Power Factor

98% at 120V, 97.2% at 277V

Battery Backup

Battery backup will operate the LED Lamp for 90 minutes if power fails. Wired for 120V-277V.

Construction

Operating Temperature

-30°C (-22°F) to 40°C (104°F)

Lens

Frosted polystyrene

Housing

Lightweight aluminum housing

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Recessed ceiling

Other

Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
